HRS FFC FPC connector 0.5mm H=2.55 right angle SMT bottom contact gold plating
Description
This Series are FPC/FFC Connectors designed for applications such as GPSs and AV equipment for automobile use or electronics for industrial and/or medical use which require resistance to vibration. These products are 0.5m pitch, bottom contact, right angle, SMT, ZIF connectors with front locking. Their structures prevent FPCs/FFCs from becoming disjointed or inserted aslant. We also offer 1mm pitch type.
Specifications
| Pitch | 0.5mm |
| Height | 2.55mm | 8-10-12-20-24-30-40-50-60-68pin available |
| Mounting Type | SMT/ZIF |
| Contact Location | Bottom contact |
| Type | Front lock |
| Current Rating | 0.5A/Pin Max |
| Voltage Rating | 50V AC/DC MAX |
| Withstanding Voltage | 250V AC,1min |
| Cover Material | LCP UL94V-0 black |
| Housing | LCP UL94V-0 Natural |
| Terminal/Contact | Copper alloy |
| Plating | Gold-plating |
| Operation Temperature | -40℃ to +85℃ |
| Lead Time | 7-10 working Days |
Our advantage
1) Technical support - both before and after sales, having outstanding professionals from like Dinkle, Anytek etc.
2) OEM/ODM - Precise mold design&development is our core competence. we service companies like Philips,Eby, Blockmaster etc.
3) Automation - Introduced latest automatic machines for assembly lines, cut the cost down and keep the quality steady more.
4) ERP - Introduced ERP management system in 2013, which assure us to bring faster response and better service to our clients.
5) One-stop solution – We manufacture terminal block,connector and enclosure. besides we have a trading company as our another professional team which can help our clients to outsource high cost-effective electronical products in china.
Product Tags:
|
|
40 Pin FFC Connector 0.5mm Pitch Images
|
